Corrugated 2 Color Slotter Flexo Printing Machine 180 Pcs/Min For Box

Product Details:
Place of Origin: China
Brand Name: RINO
Certification: CE
Model Number: HP-LD1050
Payment & Shipping Terms:
Minimum Order Quantity: 1 Set
Price: Negotiation
Packaging Details: Wrapped with film or in wooden case
Delivery Time: 40-60 Working Days After Deposit
Payment Terms: L/C, T/T
Supply Ability: 10 Set/Month
  • Detail Information
  • Product Description

Detail Information

Name: Corrugated 2 Color Slotter Flexo Printing Machine 180 Pcs/Min For Box Usage: Carton Box Printing Die Cutting
Total Weight: 20T Voltage: 220V/380V
Die Cutting Precision: ±1.5mm Tinted Precision: ±0.5mm
Total Power: 30KW Design Speed: 200 Pcs/Min
High Light:

1 Color Flexo Printing Machine

,

180Pcs/Min Flexographic Printing Machine

,

Box Flexo Printing Machine

Product Description

Corrugated 2 Color Slotter Flexo Printing Machine 180 Pcs/Min For Box





Box Flexo Printing Machine Introduction



① This machine can complete three and five-layer corrugated cardboard printing, grooving and other processes at one time by paper feeding, printing and slotting.
② The wallboard thickness is 40mm. The internal stress of the intermediate frequency quenching and tempering increases the wallboard density, hardness, strength, toughness, and conductivity. Artificial aging treatment, large processing center pair processing, high strength and high precision.
③ The transmission system adopts gear transmission 45 forging, processed by quenching and tempering, finishing and shaving technology
④ The bearing adopts international famous brand bearings such as human-centered, Harbin, etc., and is inspected one by one, and it is qualified and put into storage.





Parameter of Carton Flexo Printing Machine



Width mm 2800
Maximum Paper feeding size mm 1050×2600
Effective printing size mm 1050×2500
Minimum Paper feeding size mm 280×650
Thickness of printing plate mm 7.2
Design speed

sheets/mi

n

200
Economic speed

sheets/mi

n

180
Main motor KW 22
Total power KW 30
Weight T 20
Tinted precision mm ±0.5
Die cutting precision mm ±1.5



Main units



Corrugated 2 Color Slotter Flexo Printing Machine 180 Pcs/Min For  Box 0

Paper feeding unit



1. Pneumatic interlocking device.

2. The main motor adopts frequency conversion motor, frequency conversion control, energy saving, stable starting, with motor starting protection device



Corrugated 2 Color Slotter Flexo Printing Machine 180 Pcs/Min For  Box 1

Printing unit



1. The outer diameter is ¢330mm.

2. The surface of the steel pipe is ground and plated with hard chromium.

3. Do balance correction, stable operation.

4. Ratchet fixed reel shaft.

5. Full-page hanging board slot, suitable for 10mm×3mm hanging board.

6. Loading and unloading the printing plate, the foot switch electrically controls the forward and reverse rotation.





Packaging&shipping

20190716164038407.jpg@!w400

FAQ

1. Q:What is the machine warranty?
A: one year.
2. Q:What is the production time while placing order?
A: About 20 days
3. Q:What is the delivery time?
A: 40-60 days after get the payment.
4. Q:Can your company handle shipping for customers?
A: Yes, just give us destination sea port or container yard
5. Q:Does the packing strong?
A: Yes, all packages are double-checking before delivery
6. Q:Do you have machines in stock?
A: for standard model, we have a large quantity in stock. For special model, we need 20-30 days to produce it for you.
