Rino Packaging Machinery Co., Ltd

700*400mm PE Corrugated Box Strapping Machine With Motor Torque Limiter

Product Details:
Place of Origin: China
Brand Name: RINO
Certification: CE
Model Number: HS-PE700
Payment & Shipping Terms:
Minimum Order Quantity: 10 Set
Price: Negotiation
Packaging Details: Wrapped with film or in wooden case
Delivery Time: 20 Working Days After Deposit
Payment Terms: T/T
Supply Ability: 100 Set/Month
  • Detail Information
  • Product Description

Detail Information

Maximum Strapping Size: 700*400 Minimum Strapping Size: 150*120
Work Table Height: 320mm Machine Speed: 1.2 Knots/s
Machine Power: 0.55kw Total Weight: 160kgs
Machine Dimension: 1060*1080*1550mm Voltage: 220V/380V
Name: Carton Tying Strapping Machine PE Corrugated Box Packing Machine
High Light:

PE Corrugated Box Strapping Machine


700*400mm Corrugated Box Strapping Machine


Corrugated cardboard strapping machine

Product Description

1200 Corrugated Carton Box Strapping Machine PE Bounding Machine


Specifications of Corrugated Box PE Strapping Machine


* This machine can connect with the automatic folder gluer machine

* With motor torque limiter,while misoperation,motro iding,ensure the safety.

* Sizes of cardboard or cartons can be arbitrary adjusted.

* Strapping speed can up to 8-14 bundles per minute.

* Air pressure:0.6-0.8 Mpa.

* Power resourece:3 phase 380v

* Using material:PE tape


Specification of Strapping Machine






Max strapping size mm 700*400 1000*500 1200*800
Min strapping size mm 150*120 200*160 400*200
Workbench depth mm 320 320 320
Strapping speed s/knot 1.2 1.2 1.2
Twine used type   PE28# PE28# PE28#
Power w 550 550 550
Weight kg 160 220 230
Overall dimension mm 1060*1080*1550 1550*1160*1620 1750*1200*1700



700*400mm PE Corrugated Box Strapping Machine With Motor Torque Limiter 0
